Sheet metal cutting calculators are essential tools in the manufacturing industry, particularly for metal fabrication processes. They help determine the optimal parameters for cutting various types of sheet metal, such as steel, aluminum, or copper, to achieve precise and efficient results.
You can use the DXFReaderNET Component on a web page to upload DXF files containing the design of sheet metal components for cutting, and calculate all relevant parameters, as demonstrated in this example.
The needed parameters can be easly calculated with the built in functions of DXFReaderNET Component FindClosedAreaData and EntitiesExtensions.
Obviously, these features can be easily implemented in any desktop application.
Warning! All samples, data, places and images in this section are only
for tutorial scope. They are fictitious and may not correspond to real cases. Any similarities to actual persons, things or places is merely coincidental. The input files and any temporary files are deleted immediately after test.
